CK200219 Air Conditioning Controller

CK200219 air conditioner controller applies to the internal climate control of bus and truck.

Main functions:

  • Cooling
  • Fresh air
  • Error alarm
  • 3-grade air volume regulation
  • Logo customer-design
  • Program customer-design

Send E-mailget price

Share with:
  • description
  • technical data
  • advantage
  • Variant Products
  • Inquiry
CK200219 automatic controller applies to internal climate control of bus and truck.

Main function
Cooling YES
Heating NO
Fresh Air NO
Auto Control YES
Power lost memory YES
Error alarm YES
Auto over-voltage protection YES
Air flow regulation 3 grades
Interior temp display YES
Exterior temp display NO

The shift function (check by manual operation)
-Air outlet temp display
-Compel cooling

Power supply DC24V/12V
Power consumption 3w
Current Max.200mA
Dimensions(mm) 85x57x56mm
Input 1) Interior temp. sensor 2)Defrost sensor 3)Pressure switch 4)ACC power 5)Backlight power
Output 1)Compressor clutch 2)Fan high 3)Fan medium 4)Fan low 5)Fresh air
Display LED
Ambient temperature -30°c—80°c 5%-95%RH Non-condensing
Storage temperature -10°c—70°c 5%-95%RH Non-condensing
Display precision Temp value. Dual digit display, Accuracy,1 °c
Protection IP43
EMC EN50081&EN50082-2
Security level Applied to EN61010-II,Pollution degree :II
Weight: 110g

a.Smart Design
b.Auto Control
c.Program customer-design
d.Custom Logo

a.Fresh air ventilation button
b.Auto Control
c.Program customer-design
d.Custom Logo
