CK200216 Bus AC Controller,CK200216 passenger car air conditioner controller

CK200216 Passenger vehicle Air Condition Controller
CK200216 bus air conditioner controller applies to the climate control for bus.

Main functions:

CK200216 air conditioner controller applies to the climate control of bus, truck, agriculture machinery, etc.

Main function

Cooling	YES
Heating	YES
Fresh Air	YES
Voltage indicator	NO
Auto Control	YES
Power lost memory	YES
Error alarm	YES
Auto over-voltage protection	YES
Air flow regulation	3 grades
Interior temp display	YES
Exterior temp display	NO

The shift function (check by manual operation)
-Defrost temp display
-Compel cooling

* Describe Your Buying Requirements in Detail

Product recommendations

< >

Power supply	DC24V/12V
Power consumption	2.5w
Current	Max.200mA
Dimensions(mm)	118X54X22mm
Input	1) Interior temp. sensor 2)Defrost sensor 3)Pressure switch 4)Voltage detection 5)ACC power
Output	1)Compressor clutch 2)Fan high 3)Fan medium 4)Fan low
Display	LED
Ambient temperature	-30°c—80°c 5%-95%RH Non-condensing
Storage temperature	-10°c—70°c 5%-95%RH Non-condensing
Display precision	Temp value. Dual digit display, Accuracy,1 °c
Protection	IP54
EMC	EN50081&EN50082-2
Security level	Applied to EN61010-II,Pollution degree :II
Weight:	100g
