Application case:
USA market
Accessories:
1. Bracket: plentiful selects, or customization;
2. Lever: plentiful selects, or customization;
3. Connector: customization.
USA market
Accessories:
1. Bracket: plentiful selects, or customization;
2. Lever: plentiful selects, or customization;
3. Connector: customization.
| Power supply | DC24V /DC12V |
| Control mode | 0-10V control |
| Power consumption | 3W |
| Current | Max.108mA |
| Cable | customized |
| Torque | 4kgf.cm |
| Running time | 4±1rpm |
| Locked torque | 12kgf.cm |
| Locked current | Max.300mA |
| Noise level | Max.43dB(A) |
| Ambient temperature | -30°c—80°c |
| Storage temperature | -40°c—85°c |
| Life | Max.200,000 cycle |
| Dimensions | 83x50x28mm(actuator) 60x35x27mm(v-control box) |
| Weight | 210g |
| Quality certification | TS16949/ISO9001 |
